Paper Corrugating Machine

Quantity:
  • Shenxi

Product Description

1.Product  introduction
This machine uses the single-sided corrugated paper as raw materials, start glue application and slit the 1600mm wide paper into 15-25mm wide paper strips. And then, getting through fence and changing form from level to vertical state, compound the paper strips through belt pressing device into the core board. After the heating& drying through oven, the finished core board cut from the cutting unit should be in 1600mm in length.

2.Technical prameter
●        Model:WLFW-700

●        Production paper core width:700mm
●        Paper core thickness:10-25mm choose one size)

●        Production speed:3-10m/min

●        Adhesive: PVA

●        Suitable for 150-200g/m²high-strength corrugated recycled paper

●        Heating method: steam heating

●        Steam Pressure:≥0.75MPa

●        Equip air pressure:≥0.6MPa

●        Power supply:15KW

●        Cutting length:≤1600mm
