Edge board machine is used to make the L shape /U shape and flat-board edge protector in high speed. This machines consists of paper reel stands (11 layers, 1 layer face paper, 10 layers of core paper), gluing unit, Edge wrapping unit, Pressing unit, Cutting unit and output conveyor.
| Quantity: | |
|---|---|
Product Description
Our Automatic V Shape Edge Board Machine is a fully integrated, high-performance industrial production system, engineered to manufacture L-shape, U-shape, and flat-board paper edge protectors at consistent high speeds. Designed for industrial manufacturing clients specializing in packaging materials, this machine delivers end-to-end automation, from paper reel feeding to finished edge protector output, with a compact, space-efficient layout. The system consists of 11-layer paper reel stands (1 layer face paper, 10 layers core paper), gluing unit, edge wrapping unit, pressing unit, precision cutting unit, and output conveyor, creating a fully automated workflow that minimizes manual labor and maximizes production efficiency for industrial operations.
This high-speed paper edge protector machine supports production of three core edge protector formats: L-shape, U-shape, and flat-board, with wide adjustable size ranges to meet diverse industrial packaging needs. It eliminates the need for multiple dedicated machines, reducing capital expenditure and maximizing production flexibility for industrial clients.
Equipped with a high-precision cutting system, the machine delivers a cutting tolerance of ±0.5mm, ensuring uniform dimensions and consistent quality for every batch of edge protectors. The double-face glue applying system ensures strong lamination and structural integrity, while the multi-stage pressing unit delivers consistent forming for long-term production stability.
With production speeds of up to 40m/min for L-shape edge boards, 30m/min for U-shape, and 35m/min for flat-board, this industrial edge board making machine delivers exceptional output capacity to meet high-volume production demands. The fully automated workflow reduces manual intervention, cutting labor costs and minimizing production downtime.
With a layout footprint of 32000×800×1600mm, the machine fits seamlessly into standard industrial production facilities, while the 11kw main power system delivers energy-efficient operation, reducing long-term utility costs for manufacturing clients.
Parameter | Specification |
Supported Edge Protector Formats | L-shape, U-shape, Flat-board |
L-shape Dimension Range | 25×25mm up to 100×100mm |
U-shape Dimension Range | Inner width 20-70mm, two sides height 20-60mm |
Flat-board Width Range | 40-150mm |
Wall Thickness Range | L-shape: 2-8mm; U-shape: 2-6mm; Flat-board: 2-8mm |
Cutting Length Range | 50mm up to custom maximum length |
Cutting Precision Tolerance | ±0.5mm |
Max Production Speed | L-shape: 40m/min; U-shape: 30m/min; Flat-board: 35m/min |
Glue Application System | Double face applying glue |
Main Power | 11kw, 380V/50Hz |
Equipment Weight | 4.5 tons |
Layout Footprint | 32000×800×1600mm |
Our Automatic V Shape Edge Board Machine is an essential production asset for industrial clients across core sectors: packaging material manufacturing, furniture & woodworking, logistics & shipping supply chains, and construction & building materials. It enables high-volume production of custom edge protectors to secure fragile furniture, construction materials, electronics, and high-value cargo during shipping and storage, meeting the diverse needs of industrial manufacturing and logistics operations.
We provide full end-to-end customization for industrial manufacturing clients, with a streamlined workflow: initial consultation to assess your required edge protector formats, size ranges, and production volume targets; custom engineering of the machine configuration, including speed adjustments and production line integration; factory testing and validation of the customized equipment; on-site installation, commissioning, and operator training; and ongoing after-sales support and maintenance services to maximize long-term equipment uptime.
This machine can manufacture three core types of paper edge protectors: L-shape, U-shape, and flat-board, with fully adjustable dimensions to meet your custom industrial packaging needs.
The equipment delivers a cutting precision tolerance of ±0.5mm, ensuring consistent, uniform dimensions for every edge protector produced, even during high-volume continuous operation.
The maximum production speed is 40m/min for L-shape edge boards, 30m/min for U-shape, and 35m/min for flat-board, with fully adjustable speed settings to match your production requirements.
Yes. We offer full on-site installation, commissioning, and operator training for all our industrial clients, along with ongoing after-sales support, maintenance services, and spare parts supply to ensure long-term reliable operation.
As a leading manufacturer of advanced paper honeycomb and packaging production equipment, Shenxi has decades of experience delivering high-performance, reliable industrial solutions for manufacturing clients worldwide. Our Automatic V Shape Edge Board Machine combines advanced engineering, user-friendly operation, and full customization to help you optimize production efficiency, reduce costs, and expand your product offerings. Whether you need a standard production line or a fully customized edge board manufacturing system, our engineering team will work with you to deliver a solution that meets your exact industrial production needs. Contact us today to discuss your project.
