There are generally two models of honeycomb expanding machines, one is HEM-1450-d, and the other is HEM-1450-B. Although both models can complete the expansion of honeycomb paper, some of their specific characteristics are different. So the final results are also different. Users of this machine can choose a model that is more in line with their needs according to what they want.
Here is the content list:
What are the same characteristics of the two models of honeycomb paper expanding machines?
What are the different characteristics of the two models of honeycomb paper expanding machines?
First, introduce the effective width of the core paper. Regardless of whether the model is HEM-1450-d or HEM-1450-B, they are the same on this point. The effective width of the core paper expansion can be at least 0mm, and the maximum can reach 1400mm. The span is very large, can better meet the needs, and is very practical.
The second is the working speed of the honeycomb paper expanding machine. The two models remain the same on this point. The speed can be adjusted according to the specific conditions of the user. The slowest speed is 0.6m per minute, and the fastest can reach 4 meters per minute. Compared with manually expanding the honeycomb paper, the speed of it is significantly faster, so the work efficiency can be greatly improved. Despite the rapid action, the quality of the honeycomb paper expanding machine's work is still guaranteed, and the work can be completed quickly and well.
The feeding of the honeycomb paper in the oven is carried out in the form of a chain with a needle driving and driving the honeycomb core to start cutting. The maximum input width is 1800mm. But the maximum output width is not similar to the former. It is 400mm smaller than the maximum input width, then 1400mm. The thickness of the honeycomb is 10-70 mm. the honeycomb paper expanding machine can accept the paper with an expanded density of 120-180 grams per square meter. The cell size is in the range of 5-40mm.
Because there is a necessary heating process during the expansion of honeycomb paper, the honeycomb paper expanding machine also has the characteristics of temperature control. The user can adjust and control the heating temperature according to actual needs to obtain the expanded honeycomb paper in an ideal state. The temperature control of the honeycomb paper expanding machine can be controlled automatically. It can control the heating according to the preset temperature and keep the temperature stable. Its heating power is 18 kilowatts. Both models are controlled by the PLC (Delta) system. The air source is 4-6kg/cm3. The voltage is also consistent. Both are 3~, 380V / 50Hz.
The honeycomb paper expanding machine motor of the model HEM-1450-d has a higher power of 2.2 kilowatts and has 3 trimming blades at the same time, so it can complete the cutting work. Its size is also larger, 4600*2200*1300mm. Correspondingly, its weight is also greater. It weighs a thousand kilograms. The installed power supply reaches 20.2 kilowatts.
The honeycomb paper expanding machine motor power of the model HEM-1450-B is 0.2 kilowatts. Since there is no trimming blade, it cannot have the cutting function. The installed electric power supply is only 18.2 kilowatts. The size is 4300*2200*1350mm. The weight is 800 kg. If you are interested in our products, please consult the official website: https://www.china-honeycomb.com. Thank you very much for your support.
